Tracking Projects

The extensive use of Artificial Intelligence-based application (AI) let Tattile enhance vehicle tracking, from traditional ANPR (ALPR) reading to vehicle recognition, classification (Brand Color Class & Model) and traffic monitoring.

Highway traffic management in Republic of Srpska

tracking image

COUNTRY: Bosnia

DESCRIPTION:

In order to better utilize the capacity of the traffic network, improve the overall performance of the traffic system in all conditions, as well as to raise…

the level of traffic safety, advanced traffic management systems or Intelligent Traffic Systems (ITS) are utilized to monitor, control and manage the traffic flow.

The integrated automatic number plate recognition (ANPR) technology is part of the ITS system, which automatically takes pictures of each passing vehicle’s front, angle, or rear. Its processing software automatically detects and reads the vehicle license plates and takes action depending on the recognition results, e.g., transfer of results to the central system for further processing. The cameras used are intelligent Tattile Smart 2HD, a model specifically designed for outdoor installation and reliable performance day and night in all weather conditions.

tracking imageThe Tattile Smart 2HD cameras enable vehicle data collection at a maximum vehicle speed of 250 km/h. Cameras are installed on portals and pillars and work 24 hours / 7 days a week. In the next step, the highway operator Autoputevi Republike Srpske plans to further exploit the abilities of the Tattile by activating system functionalities such as recognition of vehicle brand and color as well as vehicle class. Also, average speed measurement or section speed control is currently planned to be installed using the Tattile camera technology. Such additional information may be particularly useful to a third party, such as, e.g., traffic police, in performing their duties. In addition to further expanding the data generation on the current highway section, the highway operator intends to expand the entire system to more highway sections in the Republic of Srpska.

Tattile chosen in Basque tender to equip main roads with traffic control cameras

samrt2HD-Spain-Basque

COUNTRY: Spain

DESCRIPTION:

At the beginning of 2022, the Smart 2HD from Tattile was chosen as the best suitable ANPR camera in a tender issued by the Basque Government in Spain…

to be installed along the main roads in the region. Local Basque authorities aim to create traffic flow statistics including an origin/destination matrix to obtain information on how and where vehicles are moving in the area. For this purpose,40 Smart 2HD have been installed on the main roads.

The traffic monitoring cameras are additionally equipped with the embedded Tattile classification algorithm. This enables to identify the vehicle class (trucks, cars, motorbikes, etc.) of the road users.

Smooth parking process at Norwegian airports with Tattile ANPR

Airport-norway-tattile

COUNTRY: Norway

DESCRIPTION:

Airports usually are busy hubs with lots of traffic moving in, out and around the airport site. The parking facilities at airports are of significant importance to ensure…

that travellers and airport visitors are in time for their flight, pick up relatives or friends, or perform other activities at the airport. Parking your car is an essential element when travelling. And parking facilities often also are a significant source of income for airports.

Operators of airport parking facilities throughout Norway, like in Bergen, Trondheim, Sander Fjord, and Stavanger, have spent considerable resources to optimise the parking experience of their customers while maximising the utilization of their parking capacity. Over 200 Basic Short Range license plate reader cameras from Tattile are deployed at these airports to improve traffic flow. In many Norwegian parking facilities, ticketless parking is introduced through ANPR cameras.

parking-norway-tattile

Pre-registered vehicles easily enter the open, barrierless parking facility. When entering and exiting, the vehicle’s license plate is scanned by the Tattile Basic ANPR cameras. The parking management system calculates the time spent in the facility, and the bill is automatically notified to the driver —no more hassle with tickets and malfunctioning barriers. New customers usually register locally in the parking facility at dedicated parking kiosks.

Ticketless parking operations have proven to optimise utilisation levels and increase customer satisfaction. The barrierless entrance and exits, in addition, are contributing to improving the capability of the facility to handle more significant amounts of traffic at peak hours and decreasing the likelihood of queueing at the entrance.

High accuracy rates, reliable performance and effective software interfaces are some of the characteristics of Tattile traffic monitoring cameras that were appreciated by Tattile partners in the region that have specialized in these innovative parking solutions.

parking-tattile

Parking enforcement in France made mobile and digital

B-mobile-parking-enforcement-france

COUNTRY: France

DESCRIPTION:

Following the decriminalisation of the non-payment of parking fees in France in 2018, the management of violations passed into the hands of municipalities…

and private companies. These companies began to establish digital parking payment verification using systems such as TePI (Traitement électronique des Plaques d’Immatriculation) which translates as “Electronic Processing of Number Plates” using smart traffic ANPR cameras such as those from Tattile.

As the name indicates, users need to enter the license plate number upon paying the parking fee and can choose from three options; either paying with cash or with credit card at a parking meter with the meter sending the plate number together with the information of the paid parking time to a central server. The second option is to pay through a smart phone app which communicated the plate number to the central server. Thirdly, drivers can obtain a subscription through a web portal and enter payment details as well as the plate number there.

A-mobile-parking-enforcement-france

In all cases the required data is sent to a central server which enables mobile parking enforcement with patrol cars that are equipped with Tattile ANPR cameras for scanning all license plates in a designated parking area.  The one-board architecture of the scanning system is built around a mobile PC and 5G + GNSS router, mounted in a customized hardware case inside the vehicle. Connected to the mobile system are the Tattile mobile ANPR cameras.

The entire system is controlled by the driver or automatically depending on the configuration via a dedicated tablet, securely mounted to the dashboard. Monitoring and telemetry are made available through various SaaS platforms updated in real-time allowing for minute-by-minute reporting and providing the observer with a live, evolving map of the state of parking ticket payment in their zone. The license plate data recorded by Tattile cameras is sent to the remote server where it is matched with all registered payments and corresponding license plates. Violations detected by the software lead to the automatic issuing of parking penalty notices.

With the proven reliability of the mobile parking enforcement technology using Tattile license plate reading cameras the main parking operator in France is now active in most of the major cities in mainland France, including the capital. In Paris alone 25 vehicles are under operation, each of them is equipped with four Tattile cameras.

One prerequisite to further establish the system in other regions is to prove the ability to interface with all major parking ticket solutions. This is maintained by the operators´ own ticket centralization server. Furthermore, according to the operator the solution is constantly evolving, and the roadmap includes other enforcement uses such as the real-time mapping of «low-emission» zones within urban areas.

The National Operative Programme

PON-Tattile-italy

COUNTRY: Italy

DESCRIPTION:

The National Operative Programme for Legality, NOP Legality, owned by the Ministry of the Interior was born in 2007 and it involved…

Basilicata, Puglia, Calabria, Campania and Sicilia.

It was entrusted with the objective of spreading better conditions of security, justice and legality for citizens and businesses, contributing to the requalification of contexts characterized by greater pervasiveness and relevance of criminal phenomena and to the increase of trust on the part of citizens and economic operations.

The main guidelines on which the Legality Programme is based can be summarized as follows:

  • Strengthening the capabilities of Public Administrations involved in the fight against organized crime and corruption making production districts safer increasing the spread of legality.
  • Strengthening the capabilities of Public Administrations involved in the fight against organized crime and corruption. It intends to carry out training activities and the financing of advanced technology equipment in order to provide information tools and expert support to Public Administration and police to improve the performance of public functions.
  • Supporting the business sector for the creation of safety conditions favouring the development of manufacturing activities. It intends to finance the provision of advanced technological tools for surveillance of production districts.

This project includes a national ANPR network which allow real-time monitoring of dangerous and illegal vehicles and in this regard Tattile supplied its ANPR cameras connected to a national database of vehicle ownership.

The installed system can correctly identify the plates of all 27 Member States of the European Union – an innovative solution which resulted in a reader complete with an inbuilt compressed database of the different plate formats.

For this project, Tattile has used its Double head ANPR camera and has developed new firmware optimised for this project. The ANPR cameras consist of two sensors: a black and white unit for the OCR and a colour camera which provides contextual overview with embedded algorithm to recognise the vehicle license plate.

The cameras are equipped with additional features like the advanced motion detection algorithm: it can detect alsovehicles without plates and without the need for an external trigger.

The collected data are sent in real time to the regional management systems and then matched with the national database (SCNTT); this allows the synchronisation of black and white lists and the continuous update of data held there.

Advanced vehicle tracking network to grant the citizens security in Turkey

turkey-citizens-security

COUNTRY: Turkey

DESCRIPTION:

The Turkish governmental forces invested in technological systems to grant the everyday life citizens’ protection and to facilitate the resolution of criminal acts…

For this purpose, Tattile, together with the great experience and certified knowledge of its trusted local partner,provided an advanced vehicle tracking network all over the country, using its sophisticated ANPR cameras.

turkey-citizens-security

Several hundred Vega Smart 2HD ANPR cameras double head family have been installed aiming to prevent crime offences. The embedded ANPR software of the traffic monitoring camera read the license plates of all vehicles passing in front of the device.

The on-board intelligence also enables to recognize vehicle features regardless of the plate number: the traffic monitoring cameras are equipped with an embedded BCC software to allow comparison between the license plate and the brand, colour, class of the vehicle. This enables the public security forces to verify if the collected data (licence plate and vehicles features) matches those registered on the provincial police archives. This feature is very useful to identify vehicles which license plate has been replaced with another one.

turkey-citizens-security

Madrid police cars patrol with mobile ANPR cameras

policecars-madrid-enforcement

COUNTRY: Spain

DESCRIPTION:

Policia Municipal de Madrid has equipped 25 of their police patrol cars with mobile ANPR/ALPR cameras provided by Tattile…

Each of the vehicles now carries a modern and equally simple architecture consisting of two ANPR cameras connected to a tablet computer. The information generated by the cameras focusses on photos taken from vehicles and herein the automatic number plate recognition. These number plate data are matched in extremely low latency with specific blacklists in a database.

This method using the integrated vehicle plate recognition software allows checking a number plate on several kinds of possible violations such as the absence of vehicle insurance, the absence of a valid technical revision plate, but also crime offences such as stolen vehicles or duplicated number plates.

Thanks to its embedded functionalities (OCR on board, GPS and Access Point Wi-Fi Integrated) and its low power consumption of just 15 W the Tattile ANPR mobile cameras allow quick ANPR camera installation in the police car and movement from one vehicle to another. This makes it the most suitable mobile ANPR police system solution for law enforcement in both in-vehicle installations and for mobile tactical operations.

Smart camera traffic surveillance for anti-terrorism measures in Belgium

Proximus-belgium-tracking-project

COUNTRY: Belgium

DESCRIPTION:

As a consequence of the terrorist attacks which shocked Paris and the whole world in 2015, the Federal Government in Belgium approved an anti-terrorism plan…

to ensure safety in everyday life for the Belgian population. Among the measures defined one of the most important action to put in place was the installation of an advanced video surveillance system using new and mature technologies for various applications, including automatic number plate recognition (ANPR) for use in the road system.

The main requirements set by the authorities for such ANPR (ALPR) technology were a robust high reading performance in all weather and light conditions as well as advanced capabilities for vehicle recognition analytics within the system. At the end of the evaluation process, the federal police in Belgium chose the smart ANPR camera system Vega Smart 2HD from Tattile for all automatic number plate recognition processes along motorways and cities across the country. Up to now, more than 700 Tattile cameras have been deployed.

In practice, the license plate software of the Vega Smart 2HD traffic surveillance cameras read the license plates of all vehicles that transit the camera positions. These license plate data are matched continuously with the national vehicle database. In addition, the Vega Smart 2HD on-board intelligence also enables to recognize vehicle features independently from the plate number. The integrated smart vehicle recognition algorithm allows triggering and sending alarms in case a specific vehicle passes under the camera and helps to solve specific situation when automatic number plate recognition is not enough, such as when police forces only know the brand and colour of a wanted vehicle or criminals keep the same vehicle but change the license plate.

First ITS highway system in Serbia

SmartCamera-installation-serbia-highway

COUNTRY: Serbia

DESCRIPTION:

In 2019 the Republic of Serbia put the first highway ITS system into operation covering about 200 highway kilometres on the Belgrade – Nis highway in central Serbia…

For this purpose, Tattile, together with the great experience and certified knowledge of its trusted local partner, provided an advanced vehicle tracking network all over the country, using its sophisticated ANPR cameras.

Several hundred Vega Smart 2HD ANPR cameras double head family have been installed aiming to prevent crime offences. The embedded ANPR software of the traffic monitoring camera read the license plates of all vehicles passing in front of the device.

The on-board intelligence also enables to recognize vehicle features regardless of the plate number: the traffic monitoring cameras are equipped with an embedded BCC software to allow comparison between the license plate and the brand, colour, class of the vehicle. This enables the public security forces to verify if the collected data (licence plate and vehicles features) matches those registered on the provincial police archives. This feature is very useful to identify vehicles which license plate has been replaced with another one.

Traffic surveillance and monitoring in the Spanish capital

traffic-monitoring-madrid-tattile

COUNTRY: Spain

DESCRIPTION:

Spanish traffic authorities (Dirección General de Trafico) have chosen Tattile cameras for a new road surveillance project in the Spanish capital Madrid…

Altogether 45 Tattile Vega Smart 2HD cctv traffic monitoring cameras have been installed for two main purposes.

The first use case involves 14 cameras which are used to control the High Occupancy Vehicle lanes (Vehículos de Alta Ocupación or VAO) in the greater area of Madrid. Road control takes place in both ways: in the morning when commuters enter the urban area of Madrid as well as in the afternoon after normal office hours when the traffic streams leaves the city again. The smart ANPR traffic cameras are used to count the number of vehicles using the VAO lanes and, at the same time, to create an origin-destination matrix.

The 31 remaining Tattile Vega Smart 2HD cameras have been deployed to analyze the traffic flow along the radial highways which are departing the center of Madrid. The information taken by these traffic surveillance smart cameras are used for different purposes such as origin-destination; definition of the travel time, and various statistics.

In addition to these everyday tasks, the newly installed Tattile traffic surveillance and monitoring cameras are used for specific campaigns, such as to check if vehicles have insurance coverage and a valid technical revision plate which is requested by law.

Tattile Anpr cameras used for vehicles tracking
COUNTRY Q.TY
DESCRIPTION
Italy 1.000 Pon project, Vehicle tracking & Prevention
Italy 350 Vehicle tracking & Prevention
Turkey 1.500 Vehicle tracking & Crime Prevention
Belgium 700 National Security
Russia 200 Sheremetyevo Airport –  Access control
Bahrain 20 Manama – Access control
Uae 50 Taxi facility
Qatar 850 Doha – Highway Monitoring
Netherland 600 General vehicles tracking
France 400 General vehicles tracking
Mongolia 70 Ulan bator – Vehicle tracking & Crime Prevention
USA 1000 Car wash applications
Sud Africa 150 Johannesburg Airport – Access control & Parking
Europe 350 Car wash applications
Germany 300 General access control
Nordic countries 400 Stavanger, Sandefjord, Trondheim, Bergen, Gotenburg – Airport Access control; Norway & Sweden – Access control (shopping mall, etc.)
New Zealand 120 Auckland, Christchurch, Wellington municipalities – Access control & Parking
Argentina 55 Vehicle tracking & Dangerous Goods Monitoring
Australia 100 Queensland, NSW, Tasmania, Victoria, WA – Access control & Parking
Mobile ANPR
COUNTRY Q.TY
DESCRIPTION
Italy 150 Local police
KSA 40 Police Authorities
Mexico 30 Mexico Federal Police
Canada 10 University security
Egypt 70 Cairo Police Authorities
Belgium 40 Patrol vans for Truck tolling enforcement
Singapore 90 Police Authorities Mobile Security enforcement
Slovack 50 Patrol vans for Truck tolling enforcement
Slovenia 20 Patrol vans for Truck tolling enforcement
Checz Rep 40 Patrol vans for Truck tolling enforcement
Spain 50 Policia Local Madrid
Turkey 40 Police Patrol monitoring
